(1) All of the control sequences and push buttons is on the panel, easy operation.
(2) The main body use high quality aluminum alloy casting, firm and solid with good airtight.
(3) Model TH-350 adopts the transparent lid. You could see the inside operating situation clearly.
(4) Our machine adopts Germany Busch vacuum pump for high quality vacuum and efficiency packing capacity.
(5) Machine covers used stainless steel shaping.
(6) Suitable for usng in factory, restaurant, food shop, supermarket, hospital, chemical factory, computer IC part package, it could keep the food in fresh and escape the rusty on component.
(7) It also fit for vacuuming out the extra air inside the epoxy resin. After we filling the epoxy in the small transformer, the air inside the epoxy is not easy to move out. It will cause the transformer in bad insulation. We could use this machine to move out the air inside it. However, this method should be by a special design in the action.
(8) We also accept the special size order.
Our
specification as the following:
Model
|
TH-350
|
TH-420
|
TH-800
|
TH-1000
|
|
Vacuum
Pump
|
1/2HP
|
1/4HP
|
1 HP
|
2 HP
|
3 HP
|
Power
Source
|
110V/220V. 1P. 50HZ/60HZ
|
220V.1P. 50/60HZ
|
220V, 380V, 415V, 440V /
3 Phase/50HZ or 60HZ
|
||
Sealing
Heater Length
|
310 mm
|
420 mm
|
2 Pcs x 800 mm
|
4 Pcs x 800 mm
|
|
Vacuum
Chamber
|
330x340x120 mm
|
450x420x130 mm
|
830x550x180 mm
|
830x550x180 mm
|
|
Mechanical
Dimensions
|
370x440x500 mm
|
480x500x900 mm
|
920x650x1050 mm
|
1870x650x1050 mm
|
